集成8核Arm Cortex-A55 CPU、NPU、GPU、MCU、DSP等多個計算單元
產品概述
產品特點
集成8核Arm Cortex-A55 CPU、NPU、GPU、MCU、DSP等多個計算單元
支持最高4K@60fps解碼和4K@25fps編碼，支持MIPI、LVDS、RGB、eDP等多種屏幕接口
支持CAN、PCIe、SDIO、USB、GMAC、SPI、TWI、UART、GPADC、LRADC、PWM等常用接口
工作環(huán)境溫度范圍-40℃~85℃
具體規(guī)格
| CPU | Octa-Core Arm Cortex-A55, up to 1.8GHz |
| MCU | RISC-V XuanTie E906, up to 200MHz |
| GPU | Arm Mali-G57 |
| NPU | 2 Tops (INT8) |
| DSP | Cadence Tensilica HiFi4 DSP |
| Memory | Support DDR3/DDR3L/LPDDR3 Support DDR4/LPDDR4/LPDDR4x |
| Video Encoder |
|
| Video Decoder |
|
| Camera | Parallel CSI - 8/10/12/16-bit width MIPI CSI - 2*4-lane/4*2-lane/ 4+2*2-lane |
| Display | Support 4-lane MIPI-DSI, 2* Dual-link LVDS, RGB, eDP and other common display output Support dual screen same content display or different content display |
| Interface | CAN *2, PCIe 2.1/USB 3.1, USB 2.0 DRD & HOST, SDIO 3.0, GMAC *2 UART *10, TWI *9, SPI *4 PWM *30, LEDC *1, CIR, OWA LRADC *2, GPADC *24 |
| Software System | Tina Linux Android |
